Our top of the line lifts are an excellent choice for any of your boat lifting needs. Our lifts are made from high grade T6 aluminum and are sturdy enough to withstand both the environment and time! These lifts are available in several sizes and come with the standard hardware listed below. If you need special sizes, we can do that too. Call us to get yours today!!!!
Pro-Lift 6000
Pro-Lift 10000
Pro-Lift 6000
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 6"x11' bottom cradle beams w/ endplates
- 2- 5/16"x17' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 3/4 HP stainl
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 6"x11' bottom cradle beams w/ endplates
- 2- 5/16"x17' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 3/4 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
- 4- guide stanchions
- 2- motor covers and pulley guards
- 4- PVC caps
- 4- 3"x6'8" PVC pipes
- standard packages includes chock hardware, bunk hardware, cover hardware, and guide stanchion hardware
Pro-Lift 8000
Pro-Lift 10000
Pro-Lift 6000
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 6H"x11' bottom cradle beams w/ extrusions and shives for 2-part pickup or endplate for 1-part pickup
- 2- 5/16"x17' stainless steel cable
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plate
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 6H"x11' bottom cradle beams w/ extrusions and shives for 2-part pickup or endplate for 1-part pickup
- 2- 5/16"x17' stainless steel cable
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 3/4 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x6'8" PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, and guide stanchion hardware
Pro-Lift 10000
Pro-Lift 10000
Pro-Lift 10000
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 8"x12'6" bottom cradle beams w/ extrusions and shives for 2-part pickup
- 2- 5/16"x31' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrad
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 8"x12'6" bottom cradle beams w/ extrusions and shives for 2-part pickup
- 2- 5/16"x31' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 3/4 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x6'8" PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, and guide stanchion hardware
Pro-LIft 13000
Pro-LIft 13000
Pro-Lift 10000
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 8H"x12'6" bottom cradle beams w/ extrusions and shives for 2-part pickup
- 2- 5/16"x31' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgra
Standard Package:
- 2- 7"x12'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 8H"x12'6" bottom cradle beams w/ extrusions and shives for 2-part pickup
- 2- 5/16"x31' stainless steel cables
- 2- 2"x8"x12' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 1 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x6'8" PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, and guide stanchion hardware
Pro-Lift 16000
Pro-LIft 13000
Pro-Lift 16000
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10"x15' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x31' stainless steel cables
- 2- 2"x10"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10"x15' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x31' stainless steel cables
- 2- 2"x10"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 1 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x10' PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, cross brace hardware, and guide stanchion hardware
Pro-Lift 20000
Pro-LIft 13000
Pro-Lift 16000
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10"x16' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x45' stainless steel cables
- 2- 3"x10"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear p
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10"x16' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x45' stainless steel cables
- 2- 3"x10"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 1 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x10' PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, cross brace hardware, and guide stanchion hardware
Pro-Lift 24000
Pro-Lift 24000
Pro-Lift 24000
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10H"x16' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x45' stainless steel cables
- 2- 3"x8"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear p
Standard Package:
- 2- 7"x15'6" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 10H"x16' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- cross braces
- 2- 5/16"x45' stainless steel cables
- 2- 3"x8"x14' wooden bunks (optional upgrade to aluminum bunks)
- 2- gear plates w/ motors (optional upgrade to gear boxes w/ 1 HP stainless C-faced motors for direct drive)
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
2- motor covers and pulley guards
4- PVC caps
4- 3"x10' PVC pipes
standard packages includes chock hardware, bunk hardware, cover hardware, cross brace hardware, and guide stanchion hardware
Pro-Lift 30000
Pro-Lift 24000
Pro-Lift 24000
Standard Package:
- 4- 8"x5'5" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 12"x17' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- welded I-beam cross braces
- 2- 3/8"x52' stainless steel cables
- 2- Dbl. 2"x12"x16' wooden bunks
- 4- Gear box wired w/ 1H SS
Standard Package:
- 4- 8"x5'5" aluminum "C" channel tops w/ loaded drive pipe, piling attachment brackets, and motor mount plates
- 2- 12"x17' bottom cradle beams w/ extrusions, shives, and deadman plates for 3-part pickup
- 2- welded I-beam cross braces
- 2- 3/8"x52' stainless steel cables
- 2- Dbl. 2"x12"x16' wooden bunks
- 4- Gear box wired w/ 1H SS C-faced motors w/ switch & GFCI
- 4- 3"x6' Weight pipe @ 45LB each
- 8- chock brackets
4- guide stanchions
4- PVC caps
4- 3"x10' PVC pipes
standard packages includes chock hardware, bunk hardware, cross brace hardware, and guide stanchion hardware
